Please contact us for more photos of MUR3060WTG
| Part Number | MUR3060WTG |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 560690 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 600V 30A 3-Pin(3+Tab) TO-247 Rail |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | MUR3060WTG |
| Datasheet download |  MUR3060WTG.pdf |
| Part Number | MUR3060WTG |
|---|---|
| Product Dimensions | 16.26 x 5.3 x 21.08 mm |
| Max Processing Temp | 260 |
| Pin Count | 3 |
| Peak Non-Repetitive Surge Current | 150 A |
| Mounting | Through Hole |
| Type | Switching Diode |
| Peak Average Forward Current | 30 A |
| Peak Reverse Repetitive Voltage | 600 V |
| Peak Reverse Recovery Time | 60 ns |
| Peak Reverse Current | 10 uA |
| Operating Temperature | -65 to 175 °C |
| Configuration | Dual Common Cathode |
| Supplier Package | TO-247 |
| Lead Finish | Matte Tin |
| Peak Forward Voltage | 1.7@15A V |
| Rad Hard | No |
| Package | 3TO-247 |
| Replacement Part Number | PART-MUR3060WTG |
| Weight | Contact us |
| Country of Origin | - |
