Please contact us for more photos of NSVBAS21TMR6T1G
| Part Number | NSVBAS21TMR6T1G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 447920 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 250V 0.2A 6-Pin SC-74 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | NSVBAS21TMR6T1G |
| Datasheet download |  NSVBAS21TMR6T1G.pdf |
| Part Number | NSVBAS21TMR6T1G |
|---|---|
| Configuration | Triple Parallel |
| Peak Non-Repetitive Surge Current | 0.625 A |
| Peak Average Forward Current | 0.2 A |
| Operating Temperature | -55 to 150 °C |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Peak Forward Voltage | [email protected] V |
| Peak Reverse Recovery Time | 50 ns |
| Mounting | Surface Mount |
| Peak Reverse Repetitive Voltage | 250 V |
| Pin Count | 6 |
| Lead Finish | Pure Tin |
| Supplier Package | SC-74 |
| Peak Reverse Current | 0.1@200V uA |
| MSL Level | 1 |
| Type | Switching Diode |
| Product Dimensions | 3 x 1.5 x 0.94 |
| Package | 6SC-74 |
| Replacement Part Number | PART-NSVBAS21TMR6T1G |
| Weight | Contact us |
| Country of Origin | - |
