Please contact us for more photos of S1G-E3 61T
| Part Number | S1G-E3 61T |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 713290 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 400V 1A 2-Pin SMA T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | S1G-E3 61T |
| Datasheet download |  S1G-E3 61T.pdf |
| Part Number | S1G-E3 61T |
|---|---|
| Pin Count | 2 |
| Peak Reverse Current | 1 uA |
| Peak Non-Repetitive Surge Current | 40 A |
| Product Dimensions | 4.6 x 2.9 mm |
| Peak Reverse Recovery Time | 1800 ns |
| Mounting | Surface Mount |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Lead Finish | Matte Tin |
| MSL Level | 1 |
| Supplier Package | SMA |
| Peak Forward Voltage | 1.1 V |
| Peak Average Forward Current | 1 A |
| Peak Reverse Repetitive Voltage | 400 V |
| Configuration | Single |
| Operating Temperature | -55 to 150 °C |
| Type | Switching Diode |
| Package | 2SMA |
| Replacement Part Number | PART-S1G-E3 61T |
| Weight | Contact us |
| Country of Origin | - |
