Please contact us for more photos of SS1F4HM3 H
| Part Number | SS1F4HM3 H |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 247890 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky Barrier Rectifier 40V 1A 2-Pin DO-219AB Plastic T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | SS1F4HM3 H |
| Datasheet download |  SS1F4HM3 H.pdf |
| Part Number | SS1F4HM3 H |
|---|---|
| Operating Temperature | -55 to 175 °C |
| Screening Level | Automotive |
| Rad Hard | No |
| Peak Forward Voltage | 0.52 V |
| Pin Count | 2 |
| Peak Reverse Current | 150 uA |
| Product Dimensions | 2.9(Max) x 1.9(Max) x 0.98(Max) |
| Configuration | Single |
| Peak Non-Repetitive Surge Current | 40 A |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Type | Schottky Barrier Rectifier |
| MSL Level | 1 |
| Lead Finish | Matte Tin |
| Peak Average Forward Current | 1 A |
| Supplier Package | DO-219AB |
| Peak Reverse Repetitive Voltage | 40 V |
| Package | 2DO-219AB |
| Replacement Part Number | PART-SS1F4HM3 H |
| Weight | Contact us |
| Country of Origin | - |
