SS2P5-M3 84A Vishay

SS2P5-M3 84A Images

Please contact us for more photos of SS2P5-M3 84A

Part Number SS2P5-M3 84A
Manufacturer Vishay
Quantity in stock 544600 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Schottky 50V 2A 2-Pin DO-220AA T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level SS2P5-M3 84A
Datasheet download SS2P5-M3 84A.pdf
Request Quotation for SS2P5-M3 84A

SS2P5-M3 84A Specifications

Part Number SS2P5-M3 84A
Lead Finish Matte Tin
Peak Reverse Current 100 uA
Mounting Surface Mount
Peak Forward Voltage 0.7 V
Peak Average Forward Current 2 A
MSL Level 1
Peak Reverse Repetitive Voltage 50 V
Peak Non-Repetitive Surge Current 50 A
Product Dimensions 3.61 x 2.18 x 1.15 mm
Supplier Package DO-220AA
Pin Count 2
Operating Temperature -55 to 150 °C
Rad Hard No
Configuration Single
Max Processing Temp 260
Type Schottky Diode
Package 2DO-220AA
Replacement Part Number PART-SS2P5-M3 84A
Weight Contact us
Country of Origin -
