Please contact us for more photos of STPS1150AY
| Part Number | STPS1150AY |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 575600 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 150V 1A 2-Pin SMA T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | STPS1150AY |
| Datasheet download |  STPS1150AY.pdf |
| Part Number | STPS1150AY |
|---|---|
| Pin Count | 2 |
| Peak Reverse Current | 1 uA |
| Operating Temperature | -40 to 175 °C |
| Rad Hard | No |
| Peak Non-Repetitive Surge Current | 50 A |
| Product Dimensions | 4.6(Max) x 2.9(Max) x 2.45(Max) |
| Screening Level | Automotive |
| Type | Schottky Diode |
| Supplier Package | SMA |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Lead Finish | Matte Tin |
| Configuration | Single |
| Peak Forward Voltage | 0.89@2V V |
| Peak Average Forward Current | 1@Tl=150C A |
| Peak Reverse Repetitive Voltage | 150 V |
| Package | 2SMA |
| Replacement Part Number | PART-STPS1150AY |
| Weight | Contact us |
| Country of Origin | - |
