Please contact us for more photos of STTH1R06U
| Part Number | STTH1R06U |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 692250 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 600V 1A 2-Pin SMB T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | STTH1R06U |
| Datasheet download |  STTH1R06U.pdf |
| Part Number | STTH1R06U |
|---|---|
| Lead Finish | Matte Tin |
| Supplier Package | SMB |
| Mounting | Surface Mount |
| Peak Reverse Repetitive Voltage | 600 V |
| Peak Forward Voltage | 1.7 V |
| Type | Switching Diode |
| Peak Non-Repetitive Surge Current | 20 A |
| MSL Level | 1 |
| Peak Average Forward Current | 1 A |
| Pin Count | 2 |
| Configuration | Single |
| Operating Temperature | -65 to 175 °C |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Product Dimensions | 4.6 x 3.95 x 2.45 mm |
| Peak Reverse Recovery Time | 45 ns |
| Peak Reverse Current | 1 uA |
| Package | 2SMB |
| Replacement Part Number | PART-STTH1R06U |
| Weight | Contact us |
| Country of Origin | - |
