Please contact us for more photos of STTH3R04S
| Part Number | STTH3R04S |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 443380 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 400V 3A 2-Pin SMC T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | STTH3R04S |
| Datasheet download |  STTH3R04S.pdf |
| Part Number | STTH3R04S |
|---|---|
| Rad Hard | No |
| Configuration | Single |
| Max Processing Temp | 260 |
| Product Dimensions | 7.15 x 6.25 x 2.45 mm |
| Pin Count | 2 |
| Peak Forward Voltage | 1.5 V |
| Operating Temperature | -65 to 175 °C |
| Peak Reverse Current | 5 uA |
| Lead Finish | Matte Tin |
| Peak Reverse Repetitive Voltage | 400 V |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Peak Average Forward Current | 3 A |
| Peak Non-Repetitive Surge Current | 60 A |
| Supplier Package | SMC |
| Type | Switching Diode |
| Peak Reverse Recovery Time | 35 ns |
| Package | 2SMC |
| Replacement Part Number | PART-STTH3R04S |
| Weight | Contact us |
| Country of Origin | - |
