Please contact us for more photos of VS-MBRB745PbF
| Part Number | VS-MBRB745PbF |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 345520 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 45V 7.5A 3-Pin(2+Tab) D2PAK Tube |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | VS-MBRB745PbF |
| Datasheet download |  VS-MBRB745PbF.pdf |
| Part Number | VS-MBRB745PbF |
|---|---|
| Lead Finish | Matte Tin |
| Product Dimensions | 10.67 x 9.65 x 4.83 mm |
| Mounting | Surface Mount |
| Peak Reverse Repetitive Voltage | 45 V |
| MSL Level | 1 |
| Peak Reverse Current | 100 uA |
| Pin Count | 3 |
| Peak Average Forward Current | 7.5 A |
| Peak Forward Voltage | 0.84@15A V |
| Operating Temperature | -65 to 150 °C |
| Peak Non-Repetitive Surge Current | 690 A |
| Configuration | Single |
| Rad Hard | No |
| Type | Schottky Diode |
| Max Processing Temp | 260 |
| Supplier Package | D2PAK |
| Package | 3D2PAK |
| Replacement Part Number | PART-VS-MBRB745PbF |
| Weight | Contact us |
| Country of Origin | - |
