DF2211UNP24V Renesas Electronics

DF2211UNP24V Images

Please contact us for more photos of DF2211UNP24V

Part Number DF2211UNP24V
Manufacturer Renesas Electronics
Quantity in stock 554120 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description MCU 16-bit 32-bit H8S CISC 64KB Flash 2.5V 3.3V 64-Pin VQFN
Category Microcontrollers MCU IC
Family 32 Bit Microcontrollers MCU
ROHS Compliant Yes
MSL Level DF2211UNP24V
Datasheet download DF2211UNP24V.pdf
Request Quotation for DF2211UNP24V

DF2211UNP24V Specifications

Part Number DF2211UNP24V
Supplier Package VQFN
Maximum Operating Supply Voltage 3.6 V
Mounting Surface Mount
Operating Temperature -20 to 75 °C
Maximum Expanded Memory Size 16 MB
Number of Programmable I/Os 37
Data Bus Width 16|32 Bit
Minimum Operating Supply Voltage 2.4|2.7|3 V
RAM Size 8 KB
On-Chip ADC 6-chx10-bit
Pin Count 64
Product Dimensions 8.2 x 8.2 x 0.89 mm
Instruction Set Architecture CISC
Interface Type H-UDI/SCI/UART/USB
Operating Supply Voltage 2.5|3.3 V
Program Memory Size 64 KB
Number of Timers 3
Rad Hard No
Maximum Speed 24 MHz
Watchdog 1
Package 64VQFN
Replacement Part Number PART-DF2211UNP24V
Weight Contact us
Country of Origin -
