Q22FA23V0007400 Seiko Instruments

Q22FA23V0007400 Images

Please contact us for more photos of Q22FA23V0007400

Part Number	Q22FA23V0007400
Manufacturer	Seiko Instruments
Quantity in stock	280170 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Crystal 12MHz 15pF 4-Pin SMD T R
Category	Logic & Timing IC
Family	Crystals
ROHS Compliant	Yes
MSL Level	Q22FA23V0007400
Datasheet download	Q22FA23V0007400.pdf

Request Quotation for Q22FA23V0007400

Q22FA23V0007400 Specifications

Part Number	Q22FA23V0007400
Frequency Aging	±5(1st)
Pin Count	4
Standard Frequency	12
Type	Crystal
Frequency Tolerance	±10
Package Dimensions	3.2 x 2.5 x 0.7
Rad Hard	No
Mode of Oscillation	Fundamental
Supplier Package	SMD
Frequency Stability	±10
Maximum Processing Temperature	260
Load Capacitance	15
Mounting	Surface Mount
Series Resistance	100
Package	4SMD
Replacement Part Number	PART-Q22FA23V0007400
Weight	Contact us
Country of Origin	-
