Q32531011003400 Seiko Instruments

Q32531011003400 Images

Please contact us for more photos of Q32531011003400

Part Number	Q32531011003400
Manufacturer	Seiko Instruments
Quantity in stock	472060 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	TH Crystal Oscillator 3.6864MHz 3.3V 15pF 4-Pin DIP Bulk
Category	Logic & Timing IC
Family	TH Crystal Oscillator
ROHS Compliant	Yes
MSL Level	Q32531011003400
Datasheet download	Q32531011003400.pdf

Request Quotation for Q32531011003400

Q32531011003400 Specifications

Part Number	Q32531011003400
Standard Frequency	3.6864 MHz
Mounting	Through Hole
Output Level	CMOS/TTL
Frequency Stability	±100 ppm
Lead Finish	Tin/Tin\|Bismuth
Rad Hard	No
Input Voltage	3.3 V
Frequency Tolerance	ppm
Supplier Package	DIP
Max Processing Temp	260
Operating Temperature	-20 to 70 °C
Product Dimensions	13.7(Max) x 6.6 x 5.1(Max)
Frequency Range
Input Level
Fabrication Technology
Frequency Aging	±5(1st) ppm/Year
Pin Count	4
Input Current	23 mA
Maximum Power Dissipation
Load Capacitance	15 pF
Package	4DIP
Replacement Part Number	PART-Q32531011003400
Weight	Contact us
Country of Origin	-
