Please contact us for more photos of BZW50-39B
| Part Number | BZW50-39B |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 854460 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode TVS Single Bi-Dir 39V 5KW 2-Pin Case R-6 |
| Category | Circuit Protection |
| Family | TVS |
| ROHS Compliant | Yes |
| MSL Level | BZW50-39B |
| Datasheet download |  BZW50-39B.pdf |
| Part Number | BZW50-39B |
|---|---|
| Lead Finish | Matte Tin |
| Maximum Clamping Voltage | 90 V |
| Mounting | Through Hole |
| Product Dimensions | 9.1 x 9.1 x 9.1 mm |
| ESD Protection | No |
| Peak Pulse Power Dissipation | 5000 W |
| Maximum Peak Pulse Current | 667 A |
| Minimum Breakdown Voltage | 43.3 V |
| Operating Temperature | -65 to 175 °C |
| Max Processing Temp | 230 |
| Direction Type | Bi-Directional |
| Rad Hard | No |
| Supplier Package | Case R-6 |
| Maximum Reverse Leakage Current | 5 uA |
| Test Current | 1 mA |
| Configuration | Single |
| Pin Count | 2 |
| Maximum Reverse Stand-off Voltage | 39 V |
| Package | 2Case R-6 |
| Replacement Part Number | PART-BZW50-39B |
| Weight | Contact us |
| Country of Origin | - |
