Please contact us for more photos of L6225PD
| Part Number | L6225PD |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 364040 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | DMOS Dual Full Bridge Driver 48V 20-Pin PowerSO Tube |
| Category | Power Management IC |
| Family | Motion Motor Control |
| ROHS Compliant | Yes |
| MSL Level | L6225PD |
| Datasheet download |  L6225PD.pdf |
| Part Number | L6225PD |
|---|---|
| Operating Supply Voltage | 48 V |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Maximum Operating Current | 10 mA |
| Shutdown Threshold | 5.5 V |
| Operating Temperature | -40 to 150 °C |
| Pin Count | 20 |
| MSL Level | 3 |
| Supplier Package | PowerSO |
| Type | DMOS Dual Full Bridge Driver |
| Rad Hard | No |
| Max Processing Temp | 245 |
| Product Dimensions | 16 x 11.1 x 3.3 mm |
| Package | 20PowerSO |
| Replacement Part Number | PART-L6225PD |
| Weight | Contact us |
| Country of Origin | - |
