Please contact us for more photos of CDRH3D16NP-100NC
| Part Number | CDRH3D16NP-100NC |
|---|---|
| Manufacturer | Sumida |
| Quantity in stock | 557420 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Shielded Wirewound 10uH 30% 100KHz Ferrite 550mA 1515 Carrier T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | CDRH3D16NP-100NC |
| Datasheet download |  CDRH3D16NP-100NC.pdf |
| Part Number | CDRH3D16NP-100NC |
|---|---|
| Rad Hard | No |
| MSL Level | 1 |
| Protection Style | Shielded |
| Test Frequency | 100 kHz |
| Product Dimensions | 4 x 4 x 1.8 mm |
| Tolerance | 30 % |
| Max Processing Temp | 260 |
| Technology | Wirewound |
| Operating Temperature | -40 to 100 °C |
| Package/Case | 1515 |
| Product Depth | 4 mm |
| Product Height | 1.8 mm |
| Product Length | 4 mm |
| Replacement Part Number | PART-CDRH3D16NP-100NC |
| Weight | Contact us |
| Country of Origin | - |
