Please contact us for more photos of EVQPF104R
| Part Number | EVQPF104R |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 418480 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Tactile N.O. SPST Round Button PC Pins 0.02A 15VDC 1.3N Thru-Hole Bulk |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | EVQPF104R |
| Datasheet download |  EVQPF104R.pdf |
| Part Number | EVQPF104R |
|---|---|
| Pole Throw Configuration | SPST |
| Max Processing Temp | 250 to 260 |
| Maximum DC Voltage Rating | 15 V |
| Maximum Current Rating | 0.02@15VDC A |
| Mounting | Through Hole |
| Lead Finish | Gold|Silver |
| Product Dimensions | 7.5 x 7.85 x 7.1 mm |
| Operating Temperature | -20 to 70 °C |
| Type | Light Touch |
| Actuator Style | Round Button |
| Rad Hard | No |
| Terminal Type | PC Pins |
| Switch Configuration | N.O. |
| Replacement Part Number | PART-EVQPF104R |
| Weight | Contact us |
| Country of Origin | - |
