Please contact us for more photos of B32022A3223M
| Part Number | B32022A3223M |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 572380 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.022uF 300VAC PP 20% 18 X 6 X 12mm RDL 15mm Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | B32022A3223M |
| Datasheet download |  B32022A3223M.pdf |
| Part Number | B32022A3223M |
|---|---|
| Mounting | Through Hole |
| Termination Style | Radial |
| Rad Hard | No |
| Tolerance | 20 % |
| Max Processing Temp | 260 |
| Lead Finish | Matte Tin |
| Dielectric | PP |
| Dielectric Material | |
| Package/Case | 18(Max) X 6(Max) X 12(Max) |
| Voltage(AC) | 300 V |
| Product Dimensions | 18 x 6 x 12 mm |
| Seated Plane Height | 12 mm |
| Lead Pitch For Radial | 15 mm |
| Operating Temperature | -40 to 110 °C |
| Capacitance Value | 0.022 uF |
| Product Depth | 6(Max) mm |
| Product Height | 12(Max) mm |
| Product Length | 18(Max) mm |
| Replacement Part Number | PART-B32022A3223M |
| Weight | Contact us |
| Country of Origin | - |
