Please contact us for more photos of B32024B3334M
| Part Number | B32024B3334M |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 275520 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.33uF 300VAC PP 20% 31.5 X 14 X 24.5mm RDL 27.5mm Bulk |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | B32024B3334M |
| Datasheet download |  B32024B3334M.pdf |
| Part Number | B32024B3334M |
|---|---|
| Dielectric Material | |
| Lead Pitch For Radial | 27.5 mm |
| Package/Case | 31.5(Max) X 14(Max) X 24.5(Max) |
| Voltage(AC) | 300 V |
| Product Dimensions | 31.5 x 14 x 24.5 mm |
| Operating Temperature | -40 to 110 °C |
| Seated Plane Height | 24.5 mm |
| Capacitance Value | 0.33 uF |
| Termination Style | Radial |
| Mounting | Through Hole |
| Rad Hard | No |
| Lead Finish | Matte Tin |
| Max Processing Temp | 260 |
| Dielectric | PP |
| Tolerance | 20 % |
| Product Depth | 14(Max) mm |
| Product Height | 24.5(Max) mm |
| Product Length | 31.5(Max) mm |
| Replacement Part Number | PART-B32024B3334M |
| Weight | Contact us |
| Country of Origin | - |
