Please contact us for more photos of B82442H1334K
| Part Number | B82442H1334K |
|---|---|
| Manufacturer | TDK |
| Quantity in stock | 371310 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind High Current Chip Molded Wirewound 330uH 10% 796KHz 20Q-Factor Ferrite 200mA 2220 Blister T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | B82442H1334K |
| Datasheet download |  B82442H1334K.pdf |
| Part Number | B82442H1334K |
|---|---|
| Protection Style | Molded |
| Type | High Current Chip |
| MSL Level | 1 |
| Package/Case | 2220 |
| Lead Finish | Tin |
| Product Dimensions | 5.9 x 5.3 x 5.3 mm |
| Core Material | Ferrite |
| Test Frequency | 796 kHz |
| Technology | Wirewound |
| Max Processing Temp | 260 |
| Tolerance | 10 % |
| Rad Hard | No |
| Product Depth | 5.3 mm |
| Product Height | 5.3 mm |
| Product Length | 5.9 mm |
| Replacement Part Number | PART-B82442H1334K |
| Weight | Contact us |
| Country of Origin | - |
