Please contact us for more photos of 1-1318116-3
| Part Number | 1-1318116-3 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 331820 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Housing M 3 POS 2.5mm Crimp ST Cable Mount Bag |
| Category | Connectors |
| Family | Connector Discrete Wire Housing |
| ROHS Compliant | Yes |
| MSL Level | 1-1318116-3 |
| Datasheet download |  1-1318116-3.pdf |
| Part Number | 1-1318116-3 |
|---|---|
| Body Orientation | Straight |
| Rad Hard | No |
| Housing Color | Black |
| Maximum Current Rating | 5/Contact |
| Wire Size | 18 AWG |
| Mounting | Cable Mount |
| Product Dimensions | 19.7 x 30.69 x 12.45 mm |
| Housing Material | Polyester |
| Number of Contacts | 3 |
| Maximum Voltage Rating | 250 |
| Gender | M |
| Number of Rows | 1 |
| Family Name | Dynamic Series Wire-Applied Connectors |
| Operating Temperature | -55 to 105 °C |
| Type | Housing |
| Pitch | 2.5 mm |
| Product Depth | 30.69 mm |
| Product Height | 12.45 mm |
| Product Length | 19.7 mm |
| Replacement Part Number | PART-1-1318116-3 |
| Weight | Contact us |
| Country of Origin | - |
