Please contact us for more photos of 1-5120528-1
| Part Number | 1-5120528-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 537630 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn IEEE 1386 RCP 64 POS 1mm Solder ST SMD T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 1-5120528-1 |
| Datasheet download |  1-5120528-1.pdf |
| Part Number | 1-5120528-1 |
|---|---|
| Termination Method | Solder |
| Mounting | Surface Mount |
| Max Processing Temp | 240|245|260|265 |
| Gender | RCP |
| Lead Finish | Tin |
| Body Orientation | Straight |
| Product Dimensions | 35.9 x 6.05 x 5.37 mm |
| Contact Plating | Gold Over Nickel |
| Pitch | 1 mm |
| Housing Material | Thermoplastic |
| Contact Material | Phosphor Bronze |
| Rad Hard | No |
| Product Depth | 6.05 mm |
| Product Height | 5.37 mm |
| Product Length | 35.9 mm |
| Replacement Part Number | PART-1-5120528-1 |
| Weight | Contact us |
| Country of Origin | - |
