Please contact us for more photos of 1-828590-0
| Part Number | 1-828590-0 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 355930 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Ejector Header HDR 10 POS 2.54mm Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 1-828590-0 |
| Datasheet download |  1-828590-0.pdf |
| Part Number | 1-828590-0 |
|---|---|
| Termination Method | Solder |
| Product Dimensions | 32 x 8.8 x 27.3 mm |
| Mounting | Through Hole |
| Body Orientation | Straight |
| Lead Finish | Tin |
| Contact Material | Brass |
| Gender | HDR |
| Max Processing Temp | 240|260|265 |
| Housing Material | Polyester |
| Pitch | 2.54 mm |
| Rad Hard | No |
| Housing Color | Gray |
| Contact Plating | Gold Over Nickel |
| Product Depth | 8.8 mm |
| Product Height | 27.3 mm |
| Product Length | 32 mm |
| Replacement Part Number | PART-1-828590-0 |
| Weight | Contact us |
| Country of Origin | - |
