Please contact us for more photos of 1059617-1
| Part Number | 1059617-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 353400 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn OSP Miniature Modular PL 0Hz to 18GHz 50Ohm Solder ST Thru-Hole Gold |
| Category | Connectors |
| Family | Connector RF |
| ROHS Compliant | Yes |
| MSL Level | 1059617-1 |
| Datasheet download |  1059617-1.pdf |
| Part Number | 1059617-1 |
|---|---|
| Contact Plating | Gold |
| Rad Hard | No |
| Impedance | 50 |
| Terminate To | PCB |
| Termination Method | Solder |
| Operating Temperature | -65 to 125 °C |
| Body Orientation | Straight |
| Contact Material | Beryllium Copper |
| Gender | PL |
| Operating Frequency | 0 to 18 GHz |
| Mounting | Through Hole |
| Type | OSP Miniature Modular |
| Max Processing Temp | 240|245|260|265 |
| Product Dimensions | 12.5 mm |
| Product Length | 12.5 mm |
| Replacement Part Number | PART-1059617-1 |
| Weight | Contact us |
| Country of Origin | - |
