Please contact us for more photos of 1565375-4
| Part Number | 1565375-4 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 818410 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board RCP 28 POS 2.2mm Solder ST Thru-Hole Tube Paper Box |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 1565375-4 |
| Datasheet download |  1565375-4.pdf |
| Part Number | 1565375-4 |
|---|---|
| Termination Method | Solder |
| Housing Material | Polybutylene Terephthalate |
| Mounting | Through Hole |
| Product Dimensions | 23.4 x 36.2 x 15.3 |
| Rad Hard | No |
| Housing Color | Natural |
| Pitch | 2.2 mm |
| Pin Count | 28 |
| Gender | RCP |
| Operating Temperature | -30 to 105 °C |
| Lead Finish | Tin Over Nickel |
| Body Orientation | Straight |
| Contact Material | Brass |
| Contact Plating | Tin Over Nickel |
| Product Depth | 36.2 mm |
| Product Height | 15.3 mm |
| Product Length | 23.4 mm |
| Replacement Part Number | PART-1565375-4 |
| Weight | Contact us |
| Country of Origin | - |
