Please contact us for more photos of 206043-1
| Part Number | 206043-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 148010 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn CPC SKT 14 POS Crimp ST Panel Mount 14 Terminal 1 Port |
| Category | Connectors |
| Family | Connector Power |
| ROHS Compliant | Yes |
| MSL Level | 206043-1 |
| Datasheet download |  206043-1.pdf |
| Part Number | 206043-1 |
|---|---|
| Mounting | Panel Mount |
| Operating Temperature | -55 to 105 °C |
| Termination Method | Crimp |
| Body Orientation | Straight |
| Family Name | Circular Plastic Connectors (CPC) |
| Strain Relief | No |
| Gender | RCP |
| Contact Gender | SKT |
| Contacts Classification | 14Signal |
| Maximum Voltage Rating | 250 |
| Number of Terminals | 14 |
| Number of Contacts | 14 |
| Drawing_URL | http://download.siliconexpert.com/pdfs/2006/12/21/pemco_a/manual/tyc/connectors/eng_cd_206043_r.pdf |
| Shell Size / Insert Arrangement | 17-14 |
| Product Dimensions | 27.18 x 36.45 x 36.45 mm |
| Number of Ports | 1 |
| Rad Hard | No |
| Product Depth | 36.45 mm |
| Product Height | 36.45 mm |
| Product Length | 27.18 mm |
| Replacement Part Number | PART-206043-1 |
| Weight | Contact us |
| Country of Origin | - |
