3-520406-2 TE Connectivity

3-520406-2 Images

Please contact us for more photos of 3-520406-2

Part Number 3-520406-2
Manufacturer TE Connectivity
Quantity in stock 622450 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Quick Disconnect Terminal 14-16AWG RCP 21.7mm 10.38mm Tin Strip
Category Connectors
Family Connector Terminals
ROHS Compliant Yes
MSL Level 3-520406-2
Datasheet download 3-520406-2.pdf
Request Quotation for 3-520406-2

3-520406-2 Specifications

Part Number 3-520406-2
Family Name Terminals & Splices
Body Material Brass
Type Quick Disconnect Terminal
Product Dimensions 21.7 x 10.38 mm
Plating Tin
Tab Size 5.16 mm²
Wire Size 14 to 16 AWG
Gender RCP
Lead Finish Tin
Product Depth 10.38 mm
Product Length 21.7 mm
Replacement Part Number PART-3-520406-2
Weight Contact us
Country of Origin -
