Please contact us for more photos of 3-794630-8
| Part Number | 3-794630-8 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 582230 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Power HDR 8 POS 3mm Solder ST Thru-Hole 8 Terminal 1 Port |
| Category | Connectors |
| Family | Connector Power |
| ROHS Compliant | Yes |
| MSL Level | 3-794630-8 |
| Datasheet download |  3-794630-8.pdf |
| Part Number | 3-794630-8 |
|---|---|
| Body Orientation | Straight |
| Rad Hard | No |
| Mounting | Through Hole |
| Max Processing Temp | 245|260 |
| Contact Plating | Tin Over Nickel |
| Lead Finish | Matte Tin |
| Operating Temperature | -40 to 105 °C |
| Gender | HDR |
| Contact Material | Brass |
| Product Dimensions | 16 x 6.86 x 9.24 mm |
| Termination Method | Solder |
| Housing Material | Nylon |
| Pitch | 3 mm |
| Product Depth | 6.86 mm |
| Product Height | 9.24 mm |
| Product Length | 16 mm |
| Replacement Part Number | PART-3-794630-8 |
| Weight | Contact us |
| Country of Origin | - |
