Please contact us for more photos of 5-104450-2
| Part Number | 5-104450-2 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 200870 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 3 POS 2.54mm Solder ST Thru-Hole Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 5-104450-2 |
| Datasheet download |  5-104450-2.pdf |
| Part Number | 5-104450-2 |
|---|---|
| Contact Plating | Tin Over Nickel |
| Pitch | 2.54 mm |
| Rad Hard | No |
| Housing Material | Thermoplastic |
| Termination Method | Solder |
| Operating Temperature | -65 to 105 °C |
| Product Dimensions | 10.16 x 6.6 x 13.59 mm |
| Housing Color | Black |
| Body Orientation | Straight |
| Contact Material | Brass |
| Mounting | Through Hole |
| Gender | HDR |
| Max Processing Temp | 240|260|265 |
| Lead Finish | Tin |
| Product Depth | 6.6 mm |
| Product Height | 13.59 mm |
| Product Length | 10.16 mm |
| Replacement Part Number | PART-5-104450-2 |
| Weight | Contact us |
| Country of Origin | - |
