Please contact us for more photos of 5084616-2
| Part Number | 5084616-2 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 796280 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Fine Pitch Connector RCP 60 POS 0.8mm Solder ST SMD T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 5084616-2 |
| Datasheet download |  5084616-2.pdf |
| Part Number | 5084616-2 |
|---|---|
| Rad Hard | No |
| Mounting | Surface Mount |
| Number of Rows | 2 |
| Lead Finish | Tin |
| Termination Method | Solder |
| Gender | RCP |
| Body Orientation | Straight |
| Contact Plating | Gold |
| Maximum Current Rating | 0.5/Contact |
| Type | Fine Pitch Connector |
| Max Processing Temp | 245|260 |
| Housing Material | Liquid Crystal Polymer |
| Maximum Contact Resistance | 30 |
| Maximum Voltage Rating | 100 |
| Operating Temperature | -40 to 85 °C |
| Housing Color | Natural |
| Family Name | Free Height (FH) Board-to-Board Connectors |
| Product Dimensions | 29.8 x 6.8 x 11.75 mm |
| Contact Material | Copper Alloy |
| Pitch | 0.8 mm |
| Product Depth | 6.8 mm |
| Product Height | 11.75 mm |
| Product Length | 29.8 mm |
| Replacement Part Number | PART-5084616-2 |
| Weight | Contact us |
| Country of Origin | - |
