Please contact us for more photos of 52947
| Part Number | 52947 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 424040 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Spring Spade Terminal 16-22AWG 20.6mm 5.16mm Tin Loose Piece |
| Category | Connectors |
| Family | Connector Terminals |
| ROHS Compliant | Yes |
| MSL Level | 52947 |
| Datasheet download |  52947.pdf |
| Part Number | 52947 |
|---|---|
| Product Dimensions | 20.6 x 5.16 mm |
| Wire Size | 16 to 22 AWG |
| Rad Hard | No |
| Stud Size | 2.84 mm |
| Body Material | Phosphor Bronze |
| Lead Finish | Tin |
| Plating | Tin |
| Product Depth | 5.16 mm |
| Product Length | 20.6 mm |
| Replacement Part Number | PART-52947 |
| Weight | Contact us |
| Country of Origin | - |
