Please contact us for more photos of 533268-3
| Part Number | 533268-3 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 148760 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn HDI RCP 96 POS 2.54mm Solder RA Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 533268-3 |
| Datasheet download |  533268-3.pdf |
| Part Number | 533268-3 |
|---|---|
| Pitch | 2.54 mm |
| Gender | RCP |
| Contact Plating | Gold |
| Mounting | Through Hole |
| Contact Material | Copper Alloy |
| Rad Hard | No |
| Product Dimensions | 100.33 x 9.14 mm |
| Lead Finish | Tin |
| Housing Color | Brown |
| Housing Material | Polyphenylene Sulfide |
| Termination Method | Solder |
| Body Orientation | Right Angle |
| Product Height | 9.14 mm |
| Product Length | 100.33 mm |
| Replacement Part Number | PART-533268-3 |
| Weight | Contact us |
| Country of Origin | - |
