Please contact us for more photos of 796188-1
| Part Number | 796188-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 379370 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn CPC SKT 24 POS Crimp ST Cable Mount 24 Terminal 1 Port |
| Category | Connectors |
| Family | Connector Power |
| ROHS Compliant | Yes |
| MSL Level | 796188-1 |
| Datasheet download |  796188-1.pdf |
| Part Number | 796188-1 |
|---|---|
| Shell Size / Insert Arrangement | 23-24 |
| Rad Hard | No |
| Contacts Classification | 24Signal |
| Termination Method | Crimp |
| Contact Gender | SKT |
| Mounting | Cable Mount |
| Type | CPC |
| Strain Relief | No |
| Number of Contacts | 24 |
| Maximum Voltage Rating | 600 |
| Number of Terminals | 24 |
| Operating Temperature | -50 to 125 °C |
| Number of Ports | 1 |
| Body Orientation | Straight |
| Product Dimensions | 45.34 mm |
| Family Name | Circular Plastic Connectors (CPC) |
| Gender | PL |
| Product Diameter | 44.86 mm |
| Product Length | 45.34 mm |
| Replacement Part Number | PART-796188-1 |
| Weight | Contact us |
| Country of Origin | - |
