Please contact us for more photos of 8-215083-8
| Part Number | 8-215083-8 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 107650 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn IDC Connector M 18 POS 2.54mm IDT RA Cable Mount Box |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 8-215083-8 |
| Datasheet download |  8-215083-8.pdf |
| Part Number | 8-215083-8 |
|---|---|
| Termination Method | IDT |
| Operating Temperature | -40 to 105 °C |
| Gender | M |
| Body Orientation | Right Angle |
| Pitch | 2.54 mm |
| Housing Material | Polyester |
| Contact Plating | Tin Over Nickel |
| Housing Color | Red |
| Mounting | Cable Mount |
| Family Name | Micro-MaTch Board-to-Board & Wire-to-Board Conn. |
| Rad Hard | No |
| Contact Material | Phosphor Bronze |
| Product Dimensions | 26.3 x 5.1 x 10.2 mm |
| Product Depth | 5.1 mm |
| Product Height | 10.2 mm |
| Product Length | 26.3 mm |
| Replacement Part Number | PART-8-215083-8 |
| Weight | Contact us |
| Country of Origin | - |
