Please contact us for more photos of 826629-2
| Part Number | 826629-2 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 741370 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Unshrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 826629-2 |
| Datasheet download |  826629-2.pdf |
| Part Number | 826629-2 |
|---|---|
| Pitch | 2.54 mm |
| Rad Hard | No |
| Contact Plating | Gold Over Nickel |
| Housing Color | Green |
| Termination Method | Solder |
| Product Dimensions | 5.08 x 2.5 x 9.5 mm |
| Operating Temperature | -65 to 105 °C |
| Body Orientation | Straight |
| Contact Material | Brass |
| Lead Finish | Tin |
| Housing Material | Polybutylene Terephthalate |
| Max Processing Temp | 240|260|265 |
| Gender | HDR |
| Mounting | Through Hole |
| Product Depth | 2.5 mm |
| Product Height | 9.5 mm |
| Product Length | 5.08 mm |
| Replacement Part Number | PART-826629-2 |
| Weight | Contact us |
| Country of Origin | - |
