Please contact us for more photos of 917783-6
| Part Number | 917783-6 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 249230 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 5 POS 2.5mm Solder ST Thru-Hole Bag |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 917783-6 |
| Datasheet download |  917783-6.pdf |
| Part Number | 917783-6 |
|---|---|
| Pitch | 2.5 mm |
| Housing Material | Nylon 6/6 |
| Rad Hard | No |
| Contact Material | Copper Alloy |
| Operating Temperature | -30 to 105 °C |
| Pin Count | 5 |
| Max Processing Temp | 265 |
| Termination Method | Solder |
| Body Orientation | Straight |
| Gender | HDR |
| Mounting | Through Hole |
| Lead Finish | Tin |
| Product Dimensions | 15 x 9.8 x 8.2 |
| Contact Plating | Tin |
| Housing Color | Blue |
| Product Depth | 9.8 mm |
| Product Height | 8.2 mm |
| Product Length | 15 mm |
| Replacement Part Number | PART-917783-6 |
| Weight | Contact us |
| Country of Origin | - |
