Please contact us for more photos of 917894-1
| Part Number | 917894-1 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 271610 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board HDR 2 POS 2.5mm Solder ST Thru-Hole Tape |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 917894-1 |
| Datasheet download |  917894-1.pdf |
| Part Number | 917894-1 |
|---|---|
| Housing Color | Natural |
| Maximum Contact Resistance | 20 |
| Termination Method | Solder |
| Maximum Current Rating | 3/Contact |
| Mounting | Through Hole |
| Max Processing Temp | 240|260|265 |
| Product Dimensions | 7.5 x 8.2 x 9.8 mm |
| Gender | HDR |
| Body Orientation | Straight |
| Maximum Voltage Rating | |
| Contact Plating | Pre-Tin |
| Operating Temperature | -30 to 105 °C |
| Number of Rows | 1 |
| Type | Wire to Board |
| Rad Hard | No |
| Pitch | 2.5 mm |
| Contact Material | Copper Alloy |
| Housing Material | Nylon 6/6 |
| Number of Contacts | 2 |
| Product Depth | 8.2 mm |
| Product Height | 9.8 mm |
| Product Length | 7.5 mm |
| Replacement Part Number | PART-917894-1 |
| Weight | Contact us |
| Country of Origin | - |
