Part Number | ADS7229IPWR |
---|---|
Manufacturer | Texas Instruments |
Quantity in stock | 164240 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | ADC Single SAR 1Msps 12-bit Serial 16-Pin TSSOP T R |
Category | Data Conversion IC |
Family | ADC |
ROHS Compliant | Yes |
MSL Level | ADS7229IPWR |
Datasheet download | ![]() |
Part Number | ADS7229IPWR |
---|---|
Voltage Supply Source | Single |
Differential Nonlinearity | ±0.5 LSB |
Digital Supply Support | No |
Input Signal Type | Single-Ended |
Sampling Rate | 1 Msps |
Rad Hard | No |
Operating Temperature | -40 to 85 °C |
Lead Finish | Gold |
Voltage Reference | External |
Max Processing Temp | 260 |
Maximum Single Supply Voltage | 5.5 V |
Full Scale Error | 0.1 % of FSR |
Pin Count | 16 |
Minimum Single Supply Voltage | 2.7 V |
Typical Single Supply Voltage | 3.3|5 V |
Maximum Power Dissipation | 38.6 mW |
Typical Power Dissipation | 30 mW |
Signal to Noise Ratio | 73.9 dB |
Number of ADCs | 1 |
Digital Interface Type | Serial (SPI) |
MSL Level | 2 |
Integral Nonlinearity Error | ±0.5 LSB |
No Missing Codes | 12 Bit |
Sample and Hold | Yes |
Architecture | SAR |
Input Voltage | 2.5/5 V |
Polarity of Input Voltage | Unipolar |
Mounting | Surface Mount |
Input Type | Voltage |
Supplier Package | TSSOP |
Differential Input | No |
Product Dimensions | 5.1 x 4.5 x 1.05 mm |
Screening Level | Industrial |
Resolution | 12 Bit |
Number of Analog Inputs | 1 |
Single-Ended Input | Yes |
Package | 16TSSOP |
Replacement Part Number | PART-ADS7229IPWR |
Weight | Contact us |
Country of Origin | - |
