Please contact us for more photos of ADS8319IDGSR
| Part Number | ADS8319IDGSR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 526740 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | ADC Single SAR 500ksps 16-bit Serial 10-Pin VSSOP T R |
| Category | Data Conversion IC |
| Family | ADC |
| ROHS Compliant | Yes |
| MSL Level | ADS8319IDGSR |
| Datasheet download |  ADS8319IDGSR.pdf |
| Part Number | ADS8319IDGSR |
|---|---|
| Maximum Power Dissipation | 22.5 mW |
| Rad Hard | No |
| Mounting | Surface Mount |
| Input Type | Voltage |
| Typical Single Supply Voltage | 5 V |
| Supplier Package | VSSOP |
| Pin Count | 10 |
| No Missing Codes | 16 Bit |
| MSL Level | 2 |
| Differential Nonlinearity | -1/1.5 LSB |
| Lead Finish | Gold |
| Sample and Hold | Yes |
| Typical Power Dissipation | 18 mW |
| Input Voltage | 4.096 V |
| Minimum Single Supply Voltage | 4.5 V |
| Voltage Supply Source | Single |
| Voltage Reference | External |
| Architecture | SAR |
| Input Signal Type | Pseudo-Differential|Differential |
| Sampling Rate | 500 ksps |
| Digital Supply Support | No |
| Polarity of Input Voltage | Unipolar |
| Product Dimensions | 3 x 3 x 1.02 mm |
| Signal to Noise Ratio | 93.9 dB |
| Operating Temperature | -40 to 85 °C |
| Digital Interface Type | Serial (3-Wire, 4-Wire, SPI) |
| Resolution | 16 Bit |
| Number of ADCs | 1 |
| Integral Nonlinearity Error | ±2.5 LSB |
| Full Scale Error | 0.03 % of FSR |
| Differential Input | Yes |
| Maximum Single Supply Voltage | 5.5 V |
| Number of Analog Inputs | 1 |
| Max Processing Temp | 260 |
| Single-Ended Input | No |
| Package | 10VSSOP |
| Replacement Part Number | PART-ADS8319IDGSR |
| Weight | Contact us |
| Country of Origin | - |
