Please contact us for more photos of DCH010505SN7
| Part Number | DCH010505SN7 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 444890 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Module DC-DC 1-OUT 5V 0.2A 1W 4-Pin SIP Module Tray |
| Category | Power Supplies |
| Family | DC to DC Power Supply |
| ROHS Compliant | Yes |
| MSL Level | DCH010505SN7 |
| Datasheet download |  DCH010505SN7.pdf |
| Part Number | DCH010505SN7 |
|---|---|
| Output Current | 0.2 A |
| Supplier Package | SIP Module |
| Pin Count | 4 |
| Mounting | Through Hole |
| Switching Regulator | Yes |
| Number of Outputs | 1 |
| Product Dimensions | 19.56 x 7.62 x 10.15 mm |
| Input Voltage | 5(TYP) V |
| Output Voltage | 5 V |
| Lead Finish | Matte Tin|Gold |
| Output Power | 1 W |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Package | 4SIP Module |
| Replacement Part Number | PART-DCH010505SN7 |
| Weight | Contact us |
| Country of Origin | - |
