DS90C363MTDX NOPB Texas Instruments

Please contact us for more photos of DS90C363MTDX NOPB

Part Number	DS90C363MTDX NOPB
Manufacturer	Texas Instruments
Quantity in stock	235030 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LVDS Flat Panel Display 0.45V 48-Pin TSSOP T R
Category	Interface IC
Family	LVDS
ROHS Compliant	Yes
MSL Level	DS90C363MTDX NOPB
Datasheet download	DS90C363MTDX NOPB.pdf

Request Quotation for DS90C363MTDX NOPB

DS90C363MTDX NOPB Specifications

Part Number	DS90C363MTDX NOPB
Minimum Operating Supply Voltage	3 V
MSL Level	2
Lead Finish	Matte Tin
Output Type	Flat Panel Display
Number of Drivers	3
Maximum Operating Supply Voltage	3.6 V
Pin Count	48
Mounting	Surface Mount
Supplier Package	TSSOP
Maximum Differential Output Voltage	0.45 V
Input Type	CMOS\|TTL
Number of Elements per Chip	3
Product Dimensions	12.5 x 6.1 x 0.9 mm
Differential Input Low Threshold Voltage	-0.1 V
Rad Hard	No
Operating Temperature	-40 to 85 °C
Maximum Power Dissipation	1980 mW
Number of Receivers	21
Transmission Data Rate	1300 Mbps
Typical Operating Supply Voltage	3.3 V
Differential Input High Threshold Voltage	0.1 V
Maximum Input Current	10 uA
Max Processing Temp	260
Package	48TSSOP
Replacement Part Number	PART-DS90C363MTDX NOPB
Weight	Contact us
Country of Origin	-
