DS90LV018ATMX NOPB Texas Instruments

Please contact us for more photos of DS90LV018ATMX NOPB

Part Number	DS90LV018ATMX NOPB
Manufacturer	Texas Instruments
Quantity in stock	790600 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LVDS Receiver 8-Pin SOIC N T R
Category	Interface IC
Family	LVDS
ROHS Compliant	Yes
MSL Level	DS90LV018ATMX NOPB
Datasheet download	DS90LV018ATMX NOPB.pdf

Request Quotation for DS90LV018ATMX NOPB

DS90LV018ATMX NOPB Specifications

Part Number	DS90LV018ATMX NOPB
Maximum Propagation Delay Time	2.5 ns
Pin Count	8
Number of Drivers	1
Input Type	LVDS
Differential Input Low Threshold Voltage	-0.1 V
Maximum Input Current	20 uA
Output Type	Receiver
Differential Input High Threshold Voltage	0.1 V
Maximum Power Dissipation	1025 mW
Supplier Package	SOIC N
Number of Receivers	1
Typical Operating Supply Voltage	3.3 V
Minimum Operating Supply Voltage	3 V
Lead Finish	Matte Tin
MSL Level	1
Product Dimensions	4.9 x 3.9 x 1.45 mm
Transmission Data Rate	400 Mbps
Screening Level	Industrial
Rad Hard	No
Operating Temperature	-40 to 85 °C
Max Processing Temp	260
Number of Elements per Chip	1
Maximum Operating Supply Voltage	3.6 V
Mounting	Surface Mount
Package	8SOIC N
Replacement Part Number	PART-DS90LV018ATMX NOPB
Weight	Contact us
Country of Origin	-
