DS90LV048ATMTCX NOPB Texas Instruments

Please contact us for more photos of DS90LV048ATMTCX NOPB

Part Number	DS90LV048ATMTCX NOPB
Manufacturer	Texas Instruments
Quantity in stock	801670 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LVDS Receiver 16-Pin TSSOP T R
Category	Interface IC
Family	LVDS
ROHS Compliant	Yes
MSL Level	DS90LV048ATMTCX NOPB
Datasheet download	DS90LV048ATMTCX NOPB.pdf

Request Quotation for DS90LV048ATMTCX NOPB

DS90LV048ATMTCX NOPB Specifications

Part Number	DS90LV048ATMTCX NOPB
Rad Hard	No
Max Processing Temp	260
Operating Temperature	-40 to 85 °C
Number of Elements per Chip	4
Product Dimensions	5 x 4.4 x 0.9 mm
Transmission Data Rate	400 Mbps
Maximum Propagation Delay Time	2.7 ns
Typical Operating Supply Voltage	3.3 V
Input Type	LVDS
Maximum Input Current	20 uA
Number of Drivers	4
Pin Count	16
Maximum Power Dissipation	1025 mW
Differential Input Low Threshold Voltage	-0.1 V
Lead Finish	Matte Tin
Differential Input High Threshold Voltage	0 V
Minimum Operating Supply Voltage	3 V
Maximum Operating Supply Voltage	3.6 V
Screening Level	Industrial
Mounting	Surface Mount
Supplier Package	TSSOP
MSL Level	1
Output Type	Receiver
Number of Receivers	4
Package	16TSSOP
Replacement Part Number	PART-DS90LV048ATMTCX NOPB
Weight	Contact us
Country of Origin	-
