Please contact us for more photos of LM4916MM NOPB
| Part Number | LM4916MM NOPB |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 870370 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Audio Amp Headphone Speaker 1-CH Mono 2-CH Stereo 0.085W Class-AB 10-Pin MSOP T R |
| Category | Amplifiers IC |
| Family | Audio Amplifier |
| ROHS Compliant | Yes |
| MSL Level | LM4916MM NOPB |
| Datasheet download |  LM4916MM NOPB.pdf |
| Part Number | LM4916MM NOPB |
|---|---|
| Function | Headphone/Speaker |
| Maximum Single Supply Voltage | 2.5 V |
| Maximum Load Resistance | 16 Ohm |
| Typical PSRR | 66 dB |
| Rail to Rail | No |
| Max Processing Temp | 260 |
| Supplier Package | MSOP |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Total Harmonic Distortion Noise | 0.1@8Ohm@25mW % |
| Amplifier Type | Class-AB |
| Input Signal Type | Single |
| Power Supply Type | Single |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Output Signal Type | Differential|Single |
| Output Type | 1-Channel Mono|2-Channel Stereo |
| Minimum Single Supply Voltage | 0.9 V |
| MSL Level | 1 |
| Product Dimensions | 3 x 3 x 0.86 mm |
| Typical Output Power x Channels @ Load | 0.085x1@8Ohm|0.014x2@16Ohm W |
| Pin Count | 10 |
| Package | 10MSOP |
| Replacement Part Number | PART-LM4916MM NOPB |
| Weight | Contact us |
| Country of Origin | - |
