Part Number | LM5008ASD NOPB |
---|---|
Manufacturer | Texas Instruments |
Quantity in stock | 436870 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conv DC-DC Single Inv Step Down 6V to 95V 8-Pin LLP EP T R |
Category | Power Management IC |
Family | DC to DC Converter |
ROHS Compliant | Yes |
MSL Level | LM5008ASD NOPB |
Datasheet download | ![]() |
Part Number | LM5008ASD NOPB |
---|---|
Operating Temperature | -40 to 125 °C |
Rad Hard | No |
Max Processing Temp | 260 |
Supplier Package | LLP EP |
Switching Frequency | 50 to 600 kHz |
Maximum Output Current | 0.35 A |
Output Voltage | 2.5 to 75 V |
Maximum Input Voltage | 95 V |
Mounting | Surface Mount |
Minimum Input Voltage | 6 V |
Output Type | Adjustable |
Number of Outputs | 1 |
Lead Finish | Tin |
Type | Inverting|Step Down |
Product Dimensions | 4 x 4 x 0.8 mm |
Pin Count | 8 |
MSL Level | 1 |
Switching Regulator | Yes |
Package | 8LLP EP |
Replacement Part Number | PART-LM5008ASD NOPB |
Weight | Contact us |
Country of Origin | - |
