LMV601MGX NOPB Texas Instruments

LMV601MGX NOPB Images

Please contact us for more photos of LMV601MGX NOPB

Part Number LMV601MGX NOPB
Manufacturer Texas Instruments
Quantity in stock 493940 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description OP Amp Single GP R-R O P 5.5V 6-Pin SC-70 T R
Category Amplifiers IC
Family OP Amp
ROHS Compliant Yes
MSL Level LMV601MGX NOPB
Datasheet download LMV601MGX NOPB.pdf
Request Quotation for LMV601MGX NOPB

LMV601MGX NOPB Specifications

Part Number LMV601MGX NOPB
Product Dimensions 2 x 1.25 x 0.9 mm
Maximum Input Offset Voltage 4@5V mV
Maximum Input Bias Current 0.00000002@5 uA
Typical Single Supply Voltage 3|5 V
Screening Level Industrial
Maximum Single Supply Voltage 5.5 V
Technology CMOS
Shut Down Support Yes
Operating Temperature -40 to 125 °C
Typical Gain Bandwidth Product 1 MHz
Typical Slew Rate 1@5V V/us
Rad Hard No
Typical Voltage Gain 116 dB
Power Supply Type Single
Minimum CMRR 86 dB
Pin Count 6
Maximum Supply Current 0.2@5V mA
Rail to Rail Rail to Rail Output
Number of Channels per Chip 1
Maximum Operating Supply Voltage 5.5 V
Minimum PSRR 82 dB
Type General Purpose Amplifier
Mounting Surface Mount
Minimum Single Supply Voltage 2.7 V
Typical Input Noise Voltage Density 39@5V nV/rtHz
Supplier Package SC-70
Typical NonInverting Input Noise Current Density 0.001@5V pA/rtHz
Package 6SC-70
Replacement Part Number PART-LMV601MGX NOPB
Weight Contact us
Country of Origin -
