Please contact us for more photos of OPA4132UA 2K5
| Part Number | OPA4132UA 2K5 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 590420 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Quad GP \u00b118V 14-Pin SOIC T R |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | OPA4132UA 2K5 |
| Datasheet download |  OPA4132UA 2K5.pdf |
| Part Number | OPA4132UA 2K5 |
|---|---|
| Typical Slew Rate | 20@±15V V/us |
| Maximum Dual Supply Voltage | ±18 V |
| Minimum Dual Supply Voltage | ±2.5 V |
| Pin Count | 14 |
| Mounting | Surface Mount |
| Technology | BiFET |
| Typical Input Noise Voltage Density | 23@±15V nV/rtHz |
| Typical Dual Supply Voltage | ±15 V |
| Type | General Purpose Amplifier |
| Maximum Operating Supply Voltage | ±18 V |
| Maximum Input Bias Current | 0.00005@±15V uA |
| Shut Down Support | No |
| Number of Channels per Chip | 4 |
| Supplier Package | SOIC |
| Typical Gain Bandwidth Product | 8 MHz |
| Product Dimensions | 8.75 x 4 x 1.5 mm |
| Maximum Input Offset Voltage | 2@±15V mV |
| Typical Voltage Gain | 120 dB |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Rail to Rail | No |
| Lead Finish | Gold |
| Typical NonInverting Input Noise Current Density | 0.003@±15V pA/rtHz |
| Power Supply Type | Dual |
| Minimum CMRR | 86 dB |
| MSL Level | 3 |
| Package | 14SOIC |
| Replacement Part Number | PART-OPA4132UA 2K5 |
| Weight | Contact us |
| Country of Origin | - |
