Please contact us for more photos of OPA4314AIPWR
| Part Number | OPA4314AIPWR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 750610 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | OP Amp Quad GP R-R I O 5.5V 14-Pin TSSOP T R |
| Category | Amplifiers IC |
| Family | OP Amp |
| ROHS Compliant | Yes |
| MSL Level | OPA4314AIPWR |
| Datasheet download |  OPA4314AIPWR.pdf |
| Part Number | OPA4314AIPWR |
|---|---|
| Minimum Dual Supply Voltage | ±9 V |
| Maximum Single Supply Voltage | 5.5 V |
| Minimum Single Supply Voltage | 1.8 V |
| Technology | CMOS |
| Operating Temperature | -40 to 125 °C |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Lead Finish | Gold |
| Rail to Rail | Rail to Rail Input/Output |
| Typical Single Supply Voltage | 3|5 V |
| MSL Level | 2 |
| Power Supply Type | Single|Dual |
| Minimum CMRR | 66 dB |
| Mounting | Surface Mount |
| Pin Count | 14 |
| Screening Level | Extended |
| Supplier Package | TSSOP |
| Maximum Input Bias Current | [email protected] uA |
| Minimum PSRR | 78 dB |
| Typical NonInverting Input Noise Current Density | [email protected] pA/rtHz |
| Typical Slew Rate | 1.5@5V V/us |
| Type | General Purpose Amplifier |
| Maximum Dual Supply Voltage | ±2.75 V |
| Product Dimensions | 5.1 x 4.5 x 1.05 mm |
| Shut Down Support | No |
| Maximum Input Offset Voltage | [email protected] mV |
| Maximum Operating Supply Voltage | 5.5 V |
| Typical Voltage Gain | 128 dB |
| Typical Input Noise Voltage Density | [email protected] nV/rtHz |
| Number of Channels per Chip | 4 |
| Typical Gain Bandwidth Product | 3 MHz |
| Package | 14TSSOP |
| Replacement Part Number | PART-OPA4314AIPWR |
| Weight | Contact us |
| Country of Origin | - |
