PTH03020WAH Texas Instruments

PTH03020WAH Images

Please contact us for more photos of PTH03020WAH

Part Number PTH03020WAH
Manufacturer Texas Instruments
Quantity in stock 556480 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Module DC-DC 1-OUT 0.8V to 2.5V 22A 10-Pin DIP Module Tray
Category Power Supplies
Family DC to DC Power Supply
ROHS Compliant Yes
MSL Level PTH03020WAH
Datasheet download PTH03020WAH.pdf
Request Quotation for PTH03020WAH

PTH03020WAH Specifications

Part Number PTH03020WAH
Type Step Down
Input Voltage 3.3(TYP) V
Mounting Through Hole
Output Voltage 0.8 to 2.5 V
Product Dimensions 37.97 x 22.1 x 8.75 mm
Lead Finish Matte Tin
Rad Hard No
Output Current 22 A
Pin Count 10
Switching Regulator Yes
Number of Outputs 1
Supplier Package DIP Module
Package 10DIP Module
Replacement Part Number PART-PTH03020WAH
Weight Contact us
Country of Origin -
