Please contact us for more photos of PTH05060WAD
| Part Number | PTH05060WAD |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 591870 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Module DC-DC 1-OUT 0.8V to 3.6V 10A 10-Pin DIP Module Tray |
| Category | Power Supplies |
| Family | DC to DC Power Supply |
| ROHS Compliant | Yes |
| MSL Level | PTH05060WAD |
| Datasheet download |  PTH05060WAD.pdf |
| Part Number | PTH05060WAD |
|---|---|
| Lead Finish | Matte Tin |
| Input Voltage | 5(TYP) V |
| Type | Step Down |
| Mounting | Through Hole |
| Switching Regulator | Yes |
| Pin Count | 10 |
| Product Dimensions | 25.27 x 15.75 x 8.75 mm |
| Number of Outputs | 1 |
| Rad Hard | No |
| Output Voltage | 0.8 to 3.6 V |
| Output Current | 10 A |
| Supplier Package | DIP Module |
| Package | 10DIP Module |
| Replacement Part Number | PART-PTH05060WAD |
| Weight | Contact us |
| Country of Origin | - |
