| Part Number | PTN78020WAH |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 774970 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Module DC-DC 1-OUT 2.5V to 12.6V 6A 90W 7-Pin DIP Module |
| Category | Power Supplies |
| Family | DC to DC Power Supply |
| ROHS Compliant | Yes |
| MSL Level | PTN78020WAH |
| Datasheet download |  PTN78020WAH.pdf |
| Part Number | PTN78020WAH |
|---|---|
| Output Power | 90 W |
| Output Voltage | 2.5 to 12.6 V |
| Switching Regulator | Yes |
| Number of Outputs | 1 |
| Input Voltage | 7 to 36 V |
| Output Current | 6 A |
| Product Dimensions | 37.97 x 22.1 x 8.75 mm |
| Mounting | Through Hole |
| Type | Step Down |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Supplier Package | DIP Module |
| Pin Count | 7 |
| Package | 7DIP Module |
| Replacement Part Number | PART-PTN78020WAH |
| Weight | Contact us |
| Country of Origin | - |
